meter size: 77mm x 44mm x 160mm
Sampling time
digit: 2.5/sec
analog: 12/sec
|
|
ACV
|
|
Range
|
Resolution
|
Accuracy
|
|
3V
|
1mV
|
+/-2.0%
+3 digits
|
|
30V
|
10mV
|
+/-0.5%
+3 digits
|
|
300V
|
100mV
|
+/-2.0%
+3 digits
|
|
750V
|
1V
|
+/-2.0%
+4 digits
|
|
1000V
|
1V
|
+/-2.0%
+4 digits
|
|
DCV
|
|
Range
|
Resolution
|
Accuracy
|
|
300mV
|
100µV;
|
+/-1.2%+2
digits
|
|
3V
|
1mV
|
+/-0.5%+2
digits
|
|
30V
|
10mV
|
+/-1.2%+2
digits
|
|
300V
|
100mV
|
+/-1.2%+2
digits
|
|
750V
|
1V
|
+/-1.5%+3
digits
|
|
1000V
|
1V
|
+/-1.5%+3
digits
|
|
Continuity
|
|
Indicator
|
Frequency
|
Sound
at
|
|
Buzzer
|
4.1Khz
|
<20
+/-10 ohm
|
|
Diode
|
|
Max
|
Resolution
|
Accuracy
|
|
0.8mA
|
1mV
|
+/-0.8%
+ 2 digits
|
|
|
Resistance
|
|
Range
|
Resolution
|
Accuracy
|
|
300ohm
|
0.1ohm
|
+/-1.2%
+ 3 digits
|
|
3Kohm
|
1ohm
|
+/-1.2%
+ 3 digits
|
|
30Kohm
|
10ohm
|
+/-1.2%
+ 3 digits
|
|
300Kohm
|
100ohm
|
+/-1.2%
+ 3 digits
|
|
3M
ohm
|
1Kohm
|
+/-1.2%
+ 3 digits
|
|
30M
ohm
|
10Kohm
|
+/-3.0%
+ 5digits
|
|
DCA
|
|
Range
|
Resolution
|
Accuracy
|
|
300µA
|
0.1µA
|
+/-1.5%+2
digits
|
|
3mA
|
1µA
|
+/-1.5%+2
digits
|
|
30mA
|
10µA
|
+/-1.5%+2
digits
|
|
300mA
|
100µA
|
+/-1.5%+2
digits
|
|
10A
|
10mA
|
+/-2.5%+
3 digits
|
|
ACA
|
|
300µA
|
0.1µA
|
+/-2.0%+4
digits
|
|
3mA
|
1µA
|
+/-2.0%+4
digits
|
|
30mA
|
10µA
|
+/-2.0%+4
digits
|
|
300mA
|
100µA
|
+/-2.0%+4
digits
|
|
10A
|
10mA
|
+/-3.0%+4
digits
|
|
|
