Item No. DMM-188
Pocket size
Auto ranging & Auto power off, Analog & Digital Dual Display
3-1/2 large display, max. 1999 counts
Display size: 16x48mm




Pocket size

To enlarge - 8 seconds
meter size: 60mm x 110mm x 12mm

Size with case: 80mm x 114mm x 16mm

ACV
Range
Resolution
Accuracy
3V
1mV
+/- 2.0% +3 digits
30V
10mV
+/- 2.0% +3 digits
300V
100mV
+/- 2.0% +4 digits
1000V
1V
+/- 2.0% +4 digits
DCV
Range
Resolution
Accuracy
300mV
100 µV
+/-1.2%+2 digits
3V
1mV
+/-0.5%+2 digits
30V
10mV
+/-1.2%+2 digits
300V
100mV
+/-1.2%+2 digits
1000V
1V
+/-1.5%+3 digits
Continuity
Indicator
Frequency
Sound at
Buzzer
4.1Khz
<20 +/-10 ohm
Diode
Max
Resolution
Accuracy
0.8mA
1mV
+/-8.0% +2 digits
Resistance
Range
Resolution
Accuracy
300ohm
0.1ohm
+/-1.2% + 3 digits
3Kohm
1ohm
+/-1.2% + 3 digits
30Kohm
10ohm
+/-1.2% + 3 digits
300Kohm
100ohm
+/-1.2% + 3 digits
3M ohm
1Kohm
+/-1.2% + 3 digits
30M ohm
10Kohm
+/-3.0% + 5 digits
DCA
Range
Resolution
Accuracy
30mA
10µA
+/-1.5%+2digits
300mA
100µA
+/-1.5%+2digits
5A
10mA
+/-2.5%+3digits
ACA
Range
Resolution
Accuracy
30mA
10µA
+/-2.0%+4digits
300mA
100µA
+/-2.0%+4digits
5A
10mA
+/-3.0%+4digits
